Item # TR860A, Everlast 8" Dia 60-Tooth 5/8" Bore .087" Plate 0.056" Thin Rim Plate 0.087" Kerf Thin Rim Saw - Alternate Top Bevel
$271.60
Download as PDF
Thank you for shopping with us!
The perfect saw to use where there is a need for a minimum of stock removal per cut, as in the cutting of plastic or veneer strips for edge banding. Maximum depth of cut on Thin Rim blade is 1-3/4 inches. Alternate design with thin saw plate and thick support hubs on both sides is available.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance crosscutting.
The perfect saw to use where there is a need for a minimum of stock removal per cut, as in the cutting of plastic or veneer strips for edge banding. Maximum depth of cut on Thin Rim blade is 1-3/4 inches. Alternate design with thin saw plate and thick support hubs on both sides is available.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance crosscutting.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Bore | 5/8 in |
| Diameter | 8 in |
| Grind | ATB |
| Kerf | 0.087 in |
| Plate | Plate Thickness 0.087 in/2.2mmThin Rim Plate Thickness 0.056 in/1.4mm |
| Teeth | 60 |
| Hook Angle | 10 deg |
