Item # TR1280T, Everlast 12" Dia 80-Tooth 1" Bore .095" Plate 0.062" Thin Rim Plate 0.091" Kerf Thin Rim Saw - Triple Chip
$342.32
Download as PDF
Thank you for shopping with us!
The perfect saw to use where there is a need for a minimum of stock removal per cut, as in the cutting of plastic or veneer strips for edge banding. Maximum depth of cut on Thin Rim blade is 1-3/4 inches.
The perfect saw to use where there is a need for a minimum of stock removal per cut, as in the cutting of plastic or veneer strips for edge banding. Maximum depth of cut on Thin Rim blade is 1-3/4 inches.
Alternate design with thin saw plate and thick support hubs on both sides is available.
Triple Chip Grind - TCG - This design uses a trapezoidal tooth with 45 deg bevel on each side, which performs the cutting work followed by a lower STR tooth (raker) tooth for clean-out. Strong tooth design for cutting harder materials such as manmade laminates (single-sided) and non-ferrous materials. Can be used for rip cutting and cross cutting.
SPECIFICATIONS | |
Manufacturer | Everlast |
---|---|
Bore | 1 in |
Diameter | 12 in |
Grind | TCG |
Kerf | 0.091 in |
Plate | Plate Thickness 0.095 in/2.4mmThin Rim Plate Thickness 0.062 in/1.6mm |
Teeth | 80 |
Hook Angle | 5 deg |
