Item # TC20510, Everlast Truss & Component Saw - 20.5" Dia 100-Tooth 1.5" Bore 0.150" Plate 0.225" Kerf
$584.56
Download as PDF
Thank you for shopping with us!
These saws are the workhorses of truss plants and are designed to provide a long service life and excellent cutting performance. Countersunk (80°) holes will accept 5/16" flat head bolt.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance cross cutting.
These saws are the workhorses of truss plants and are designed to provide a long service life and excellent cutting performance. Countersunk (80°) holes will accept 5/16" flat head bolt.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance cross cutting.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Bore | 1.5 in |
| Diameter | 20.5 in |
| Countersink | 8 - Right |
| Kerf | 0.225 in - 5.7 mm |
| Machine | Alpine Linear |
| Grind | ATB |
| Plate | 0.150 in - 3.8 mm |
| Teeth | 100 |
| Hole Size | 2.25 in Bolt Hole Circle Dia |
