Item # PLJ201004, Everlast 20" Dia 100-Tooth 1" Bore 0.102" Plate 0.142" Kerf Plex-Cut Saw - TC45
$448.50
Download as PDF
Thank you for shopping with us!
Special tooth design for cutting plastics where melting is a problem, such as nylon, acrylic, plexiglass, lucite, ABS, lexan, and PVC pipe. Good for material thickness up to 3/8" . Please call for cutting materials in excess of 3/8" . Special design available for vinyl extrusion cutting.
Modified Triple Chip Grind - TC45 - This design starts with TCG configuration, but the STR (raker) tooth has small 45 degree chamfer. The addition of this chamfer, along with special clearances, provides the best possible finish on double face laminate and solid surface materials. This design provides good service life with excellent surface finish on table saws and radial arm saws.
Special tooth design for cutting plastics where melting is a problem, such as nylon, acrylic, plexiglass, lucite, ABS, lexan, and PVC pipe. Good for material thickness up to 3/8" . Please call for cutting materials in excess of 3/8" . Special design available for vinyl extrusion cutting.
Modified Triple Chip Grind - TC45 - This design starts with TCG configuration, but the STR (raker) tooth has small 45 degree chamfer. The addition of this chamfer, along with special clearances, provides the best possible finish on double face laminate and solid surface materials. This design provides good service life with excellent surface finish on table saws and radial arm saws.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Bore | 1 in |
| Diameter | 20 in |
| Grind | TC45 |
| Kerf | 0.142 / 3.6 mm |
| Note | -- |
| Plate | 0.102 in / 2.6 mm |
| Teeth | 100 |
| Hook Angle | 20 deg |
