Item # PLJ161005AF, Everlast 16" Dia 100-Tooth 1" Bore 0.102" Plate 0.125" Kerf Plex-Cut Saw - AR/AFB
$389.86
Download as PDF
Thank you for shopping with us!
Special tooth design for cutting plastics where melting is a problem, such as nylon, acrylic, plexiglass, lucite, ABS, lexan, and PVC pipe. Good for material thickness up to 3/8" . Please call for cutting materials in excess of 3/8" . Special design available for vinyl extrusion cutting.
PLJ141005AF- 5 degree alternate face bevel--provide angle bevel on tooth face for ATB grind only.
Special tooth design for cutting plastics where melting is a problem, such as nylon, acrylic, plexiglass, lucite, ABS, lexan, and PVC pipe. Good for material thickness up to 3/8" . Please call for cutting materials in excess of 3/8" . Special design available for vinyl extrusion cutting.
PLJ141005AF- 5 degree alternate face bevel--provide angle bevel on tooth face for ATB grind only.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Bore | 1 in |
| Diameter | 16 in |
| Grind | AR/AFB |
| Kerf | 0.125 / 3.2 mm |
| Note | 5 degree alternate face bevel |
| Plate | 0.102 in / 2.6 mm |
| Teeth | 100 |
| Hook Angle | 20 deg |
