Item # LU74R008, Freud Thin Kerf Ultimate Cut-Off Blades: LU74R Series
Original price was: $69.26.$62.33Current price is: $62.33.
Download as PDF
Thank you for shopping with us!
Application: Ultimate Cut-Off Blades for Glass-Smooth Finishes with Underpowered Saws
This thin kerf blade produces glass smooth surfaces when crosscutting hardwoods and softwoods, thanks to Freud's unique side grinding technology. The larger blades are ideal for miter box applications. Thin kerf blades remove less material than standard carbide blades, thus requiring less horsepower to produce equally good results.
Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance. No Stabilizers needed. Unique Side Grind polishes the material to produce a superior finish. Perma-Shield™ Non-Stick Coating reduces blade drag, protects the blade from corrosion and pitch buildup.
Ideal For: Ultimate Cut-Off Blades For Glass-Smooth Finishes with Underpowered Saws. Depth of cut (1/4" min to 1-5/8" max).
Tip: Maintain a proper feed rate. Feeding too slow causes burning of the material. Feeding too fast can be dangerous and produces a poor dull cut.
Application: Ultimate Cut-Off Blades for Glass-Smooth Finishes with Underpowered Saws
This thin kerf blade produces glass smooth surfaces when crosscutting hardwoods and softwoods, thanks to Freud's unique side grinding technology. The larger blades are ideal for miter box applications. Thin kerf blades remove less material than standard carbide blades, thus requiring less horsepower to produce equally good results.
Premium TiCo™ HI-Density Carbide Crosscutting Blend for Maximum Performance. No Stabilizers needed. Unique Side Grind polishes the material to produce a superior finish. Perma-Shield™ Non-Stick Coating reduces blade drag, protects the blade from corrosion and pitch buildup.
Ideal For: Ultimate Cut-Off Blades For Glass-Smooth Finishes with Underpowered Saws. Depth of cut (1/4" min to 1-5/8" max).
Tip: Maintain a proper feed rate. Feeding too slow causes burning of the material. Feeding too fast can be dangerous and produces a poor dull cut.
| SPECIFICATIONS | |
| Diameter | 8 in |
|---|---|
| Arbor | 5/8 in |
| Kerf | .087 in |
| Hook Angle | 10 deg |
| Plate | .063 in |
| Teeth | 64 ATB |
| Type | Perma-SHIELD |
| Manufacturer | Freud Tools |
