Item # IL-25080H3, Tenryu Industrial Blade Series for Sliding Table Saws/Vertical Panel Saws
$114.84
Download as PDF
Thank you for shopping with us!
Table Saws. Panel Saws.
Tenryu's European industrial quality line for heavy duty applications.
Each Blade Features:
-Select grade of carbide tip for better performance
-Large European style tips
-Heavy, European plate-style resists deflection during cutting
-Resin bond, laser slots to absorb and eliminate vibration to produce a cleaner, quieter, more efficient cut
Note: This series is designed for fitting metric-sized saws (250mm - 350mm diameter) with dedicated 30mm arbors, and the following pin-hole patterns:
(# of holes)-(hole diameter)-(bolt circle)
2-7.0mm-42.0mm
2-9.0mm-46.0mm
2-10.0mm-60.0mm
Table Saws. Panel Saws.
Tenryu's European industrial quality line for heavy duty applications.
Each Blade Features:
-Select grade of carbide tip for better performance
-Large European style tips
-Heavy, European plate-style resists deflection during cutting
-Resin bond, laser slots to absorb and eliminate vibration to produce a cleaner, quieter, more efficient cut
Note: This series is designed for fitting metric-sized saws (250mm - 350mm diameter) with dedicated 30mm arbors, and the following pin-hole patterns:
(# of holes)-(hole diameter)-(bolt circle)
2-7.0mm-42.0mm
2-9.0mm-46.0mm
2-10.0mm-60.0mm
| SPECIFICATIONS | |
| Diameter | 250 mm |
|---|---|
| Application | Chip-free cutting on double-sided low-pressure laminate w/o scoring blade |
| Arbor | 30 mm |
| Grind | HATB |
| Kerf | 0.118 |
| Manufacturer | Tenryu |
| Rake | -5 |
| RPM | 5,870 |
| Teeth | 80 |
| Type | Double-sided low-pressure laminate (Melamine) w/no scoring blade use |
