Item # HD143670A, Everlast 14" 36-Tooth 0.118" Plate 0.170" Kerf Heavy Duty Rip Saw - - 70mm - 2 keyways - 20mm W x 5mm D
$207.64
Download as PDF
Thank you for shopping with us!
HD-series saws are specially designed for fast cutting on both manual and power feed ripping operations. Design features include large gullets, heavier plates, and use of the proper clearances designed for this type of heavy duty cutting in both hard or soft woods. Modifications such as special grinds, bores, keyways, and pinholes can be provided on all GL and HD items.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance crosscutting.
HD-series saws are specially designed for fast cutting on both manual and power feed ripping operations. Design features include large gullets, heavier plates, and use of the proper clearances designed for this type of heavy duty cutting in both hard or soft woods. Modifications such as special grinds, bores, keyways, and pinholes can be provided on all GL and HD items.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance crosscutting.
SPECIFICATIONS | |
Manufacturer | Everlast |
---|---|
Diameter | 14 in |
Bore | 70 mm - 2 keyways - 20 mm W x 5mm D |
Grind | ATB |
Kerf | 0.170 in / 4.3 mm |
Plate | 0.118 in / 3.0 mm |
Teeth | 36 |
Hook Angle | 20 deg |
