Item # DFL2206430, Everlast Astra Series 220mm Dia 64-Tooth 30mm Bore 2.2mm Plate 2.9mm Kerf Panel Saw (Metric Diameter MICRO-5 Tip)
$173.14
Download as PDF
Thank you for shopping with us!
The perfect saw for cutting double-sided materials such as Melamine, Kortron, and Veneer. Can be used on radial or table saws.
High Alternate Top Bevel - Hi ATB - Identical configuration to ATB, but each tooth has top bevel of 30 degrees or more. The greater angle can cause faster wearing/dulling. Combine with Micro-5 carbide to increase time between sharpenings. Ideal for cutting of laminated materials. Provides a fine cutting finish with proper sharpening. An Alternate Face Bevel (AFB) can be added to this design upon request.
MICRO-5 extra hard tips provide 3 to 5 times longer service than standard carbide.
The perfect saw for cutting double-sided materials such as Melamine, Kortron, and Veneer. Can be used on radial or table saws.
High Alternate Top Bevel - Hi ATB - Identical configuration to ATB, but each tooth has top bevel of 30 degrees or more. The greater angle can cause faster wearing/dulling. Combine with Micro-5 carbide to increase time between sharpenings. Ideal for cutting of laminated materials. Provides a fine cutting finish with proper sharpening. An Alternate Face Bevel (AFB) can be added to this design upon request.
MICRO-5 extra hard tips provide 3 to 5 times longer service than standard carbide.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Bore | 30 mm |
| Diameter | 220 mm |
| Grind | 30 deg ATB |
| Hook Angle | -5 deg |
| Kerf | 0.115 in |
| Plate | 0.087 in |
| Teeth | 64 |
| Pinholes | 2/7/42 |
