Item # DCO1080RH, Everlast 10" Diameter 80-Tooth 5/8" Bore Right Hand 15° Hook .087 Plate 0.130 Kerf Double Cut-Off and Trim Saws - 4 & 1 Grind
$207.00
Download as PDF
Thank you for shopping with us!
Extra plate thickness gives these saws extreme stability when used on Double End or Panel Sizing machines, resulting in a splinter free finish on either sizing or angular cuts.
Other groupings such as 2+1, 3+1, up to 9+1 available when number of teeth allow.
4 + 1 - Four ATB teeth are followed by one ATB with bevel in opposite direction. Used for Double Cut Off machines where Left Hand (LH) and Right Hand (RH) blades are used to size materials during the cutting process. Pay special attention when ordering these blades due to the RH and LH configurations
Extra plate thickness gives these saws extreme stability when used on Double End or Panel Sizing machines, resulting in a splinter free finish on either sizing or angular cuts.
Other groupings such as 2+1, 3+1, up to 9+1 available when number of teeth allow.
4 + 1 - Four ATB teeth are followed by one ATB with bevel in opposite direction. Used for Double Cut Off machines where Left Hand (LH) and Right Hand (RH) blades are used to size materials during the cutting process. Pay special attention when ordering these blades due to the RH and LH configurations
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Diameter | 10 in |
| Bore | 5/8 in |
| Grind | RH |
| Kerf | 0.130 in (3.3 mm) |
| Plate | 0.087 in (2.2 mm) |
| Teeth | 80 |
| Hook Angle | 15 deg |
