Item # 99-569, Freud Quadra-Cut™ Raised Panel Bits with Backcutters
Original price was: $133.28.$119.95Current price is: $119.95.
Download as PDF
Thank you for shopping with us!
Application: Produces panels from 3/4" stock that are flush with the doorframe for a professional, architecturally correct appearance (see video below for more information on Quadra-Cut™ Design)
-Exclusive design combines a backcutter with the smooth cuts of Freud's Quadra-Cut™ Raised Panel Bits.
-Shims are included to allow adjustment of tongue thickness from 7/32" to 1/4" for maximum versatility and compatibility.
-Patented design allows these bits to produce a full 1 1/2" wide reveal for traditional raised panel doors.
-Included 54-562 radius backcutter gives double-sided appearance and can be replaced with optional 54-560 square backcutter for a more contemporary look.
-Cuts all composition materials, plywoods, hardwoods, softwoods.
-Use on table-mounted portable routers.
Application: Produces panels from 3/4" stock that are flush with the doorframe for a professional, architecturally correct appearance (see video below for more information on Quadra-Cut™ Design)
-Exclusive design combines a backcutter with the smooth cuts of Freud's Quadra-Cut™ Raised Panel Bits.
-Shims are included to allow adjustment of tongue thickness from 7/32" to 1/4" for maximum versatility and compatibility.
-Patented design allows these bits to produce a full 1 1/2" wide reveal for traditional raised panel doors.
-Included 54-562 radius backcutter gives double-sided appearance and can be replaced with optional 54-560 square backcutter for a more contemporary look.
-Cuts all composition materials, plywoods, hardwoods, softwoods.
-Use on table-mounted portable routers.
| SPECIFICATIONS | |
| Manufacturer | Freud Tools |
|---|---|
| Cut Height, Length, or Width | 1 in |
| Diameter | 3 1/2 in |
| Minor Height | 5/32 in |
| Overall Length | 3 in |
| R1/Radius | 1 1/2 in |
| R2/Radius | 3/16 in |
| Shank | 1/2 in |
| Type | Bit |
