Item # 821-102, Mastercut 4 Flute Mortise Compression
$149.38
Download as PDF
Thank you for shopping with us!strong>
Material Finish-Top: Excellent
Material Finish-Bottom: Excellent
Compression routers are best used when both top and bottom finish are important. They’re best used with material that has laminate on both the top and bottom. Chips flow in a sideways direction.
Endmill Points are most often found on 3 and 4 flute routers. They’re good for achieving a smooth finish on a flat bottom surface, and are commonly used in the plastic routing industry.
Material Finish-Top: Excellent
Material Finish-Bottom: Excellent
Compression routers are best used when both top and bottom finish are important. They’re best used with material that has laminate on both the top and bottom. Chips flow in a sideways direction.
Endmill Points are most often found on 3 and 4 flute routers. They’re good for achieving a smooth finish on a flat bottom surface, and are commonly used in the plastic routing industry.
| SPECIFICATIONS | |
| Diameter | 1/2 in |
|---|---|
| Cut Height, Length, or Width | 7/8 in |
| End Pt Type | Endmill |
| Flute Geometry | Mortise |
| Flute | 4 |
| Helix Angle | 30 deg |
| Overall Length | 3 in |
| Shank | 1/2 in |
| Manufacturer | Mastercut |
