Item # 77-603, Freud Premier Solid Carbide Mortise Compression Spiral Bit
Original price was: $76.86.$69.17Current price is: $69.17.
Download as PDF
Thank you for shopping with us!
Application: Mortises or grooves with a perfect top surface, or through-cuts in thin double-sided veneers and laminates
-Shorter up shear length allows bit to be used for grooves and mortises without chipping top surface.
-Also ideal for through-cuts in double-sided sheets that are 5/8" thick or less.
-Combination of up and down shear flutes eliminates chipping on both sides of double-sided panels.
-Routs melamine, veneer plywood, and other double-sided materials, as well as hardwood and softwood.
-Use on CNC and other automatic routers as well as handheld and table-mounted portable routers.
-Double flute spirals are for extra clean cuts at faster feed rates.
-Black I.C.E.™ coating for cool cutting edge and superior chip evacuation. Black I.C.E.™ + Freud TiCo™ Hi-Density Carbide = 2X increased life and performance vs. standard uncoated bits. Black ICE Router Bits—the slickest technology in solid carbide router bits—protects solid carbide cutting edge by creating a slick, lubricant-like action for a cool cutting edge and superior chip evacuation.
Application: Mortises or grooves with a perfect top surface, or through-cuts in thin double-sided veneers and laminates
-Shorter up shear length allows bit to be used for grooves and mortises without chipping top surface.
-Also ideal for through-cuts in double-sided sheets that are 5/8" thick or less.
-Combination of up and down shear flutes eliminates chipping on both sides of double-sided panels.
-Routs melamine, veneer plywood, and other double-sided materials, as well as hardwood and softwood.
-Use on CNC and other automatic routers as well as handheld and table-mounted portable routers.
-Double flute spirals are for extra clean cuts at faster feed rates.
-Black I.C.E.™ coating for cool cutting edge and superior chip evacuation. Black I.C.E.™ + Freud TiCo™ Hi-Density Carbide = 2X increased life and performance vs. standard uncoated bits. Black ICE Router Bits—the slickest technology in solid carbide router bits—protects solid carbide cutting edge by creating a slick, lubricant-like action for a cool cutting edge and superior chip evacuation.
| SPECIFICATIONS | |
| Manufacturer | Freud Tools |
|---|---|
| Diameter | 3/8 in |
| Cut Height, Length, or Width | 7/8 in |
| Flute | 3 |
| Overall Length | 3 in |
| Shank | 3/8 in |
| Upcut Length | 1/4 in |
