Item # 61346, Amana Tool Insert Carbide Adjustable Groove with Scorer & Ring Nut 180mm (7-1/16) Dia x 4.0 to 7.5mm (5/32 to 19/64) x 1-1/4 Bore (Industrial)
$477.77
Download as PDF
Thank you for shopping with us!
Hard wearing steel body complete with tungsten carbide knives and scorer for improved finish. Suitable for producing various thickness grooves and slots in softwood, hardwood, and man-made boards (with or without coating) on a spindle molder. Cutting width can be adjusted in 0.1mm increments by special threaded bushing and scale without removing the cutter from the spindle.
Hard wearing steel body complete with tungsten carbide knives and scorer for improved finish. Suitable for producing various thickness grooves and slots in softwood, hardwood, and man-made boards (with or without coating) on a spindle molder. Cutting width can be adjusted in 0.1mm increments by special threaded bushing and scale without removing the cutter from the spindle.
| SPECIFICATIONS | |
| Manufacturer | Amana Tool |
|---|---|
| Diameter | 7 1/16 in |
| Bore | 1 1/4 in |
| Cut Height, Length, or Width | 5/32 in to 19/64 in |
| Knives | RCK-18, RCK-71 |
| Note | -- |
| Overall Length | 7 1/16 in |
| Part Descp. | Adjustable Grooving w/Scorer & Ring Nut 4mm to 7.5mm |
| RPM | 4,300 to 7,500 |
| Replacement Parts | Allen Cap Screw #67006 |
| Teeth | 8+4 |
